Hydraulic Shearing Machine for Cutting Metal Plate (QC11Y)

Overview

Basic Info.

Model NO.	QC11Y
Control	Manual
Power Source	Hydraulic
Layout	Horizontal
Max.Lxwxh:4920X2250X3300	Max.Weight:28000kg
Transport Package	Wooden Cases
Trademark	SMAC
Origin	China

Packaging & Delivery

Package Size 345.00cm * 160.00cm * 180.00cm Package Gross Weight 1000.000kg

Product Description

Product Description

Specifications:
1) All steel welded structure
2) Vibrating treatment of ageing for removal of internal stress
3) Integrated hydraulic transmission system, with good reliability
4) Triple support rolling guide rail to eliminate gaps of support and
Enhance shearing quality
5) Mechanical rear stopper with manual fine tuning and digital indication
Clearance in between shearing blades adjusted by hand wheel for speed,
Accuracy and convenience
6) Rectangular blades with four cutting edges to prolong working life
7) Adjustable shearing angle to reduce deformation of the sheet
8) Upper blade holder has inward tilting structure to facilitate material
Feed in and also enhance working accuracy
9) Sectional shearing function
10) Light aligning function
11) Optional rear material holding device

Type	Cutting Thickness (mm)	Cutting Length (mm)	Cutting Angel (° )		Stopper Adjust Range (mm)	Number stroke	Power (kw)	Dimension L× W× H (mm)
4× 2500	4	2500	1° 30′		20-600	17	5.5	3450× 1600× 1800
4× 3200	4	3200	1° 30′		20-600	17	7.5	4150× 1600× 1800
6× 2500	6	2500	1° 30′		20-600	17	7.5	3150x1600× 1800
6× 3200	6	3200	1° 30′		20-600	17	7.5	3900× 1600× 1800
6x4000	6	4000	1° 12′		20-600	17	11	4750× 1678× 1880
8x2500	8	2500	1° 30′		20-600	17	11	3150× 1676x1880
8x3200	8	3200	2° 30′		20-600	17	11	3840× 1676x1880
8x4000	8	4000	1° 12′		20-600	17	11	4950× 1775× 1990
10× 2500	10	2500	1° 30′		20-600	9	15	3150× 1676x1880
10× 3200	10	3200	1° 30′		20-600	9	15	3150× 2515x1960
12× 2500	12	2500	1° 30′		20-600	8	22	3400× 3100× 2160
16× 4000	16	6000	2° 30′		20-700	9	30	5650× 2500× 2400
20× 4000	20	4000	3° 30′		20-700	5	45	4985× 2410× 2980
