Plate and Tube Integrated Laser Cutting Machine

Basic Info.

Model NO.	Kehui
Technical Class	Pulse Laser
Applicable Material	Metal
Structure Type	Gantry Type
Laser Classification	Free Electron Laser
Laser Technology	Laser Control Fault Cutting
Working Accuracy	+-0.01mm
Laser Power	1000W 1500W 2000W 3000W 4000W 6000W 8000W 10000W
Marking Area	110mm*110mm
Wavelength	1064mm
Core Components	Engine, Gear
Marking Speed	8000mm/S
Transport Package	Plywood Box
Specification	140X38X28 Cm
Origin	China
Production Capacity	5000 Pieces/Month

Packaging & Delivery

Package Size 1050.00cm * 230.00cm * 170.00cm Package Gross Weight 5900.000kg

Product Description

Fiber Laser Cutting Machine
Working area	1500*3000mm
Optional Working Area	1300*2500mm, 2000*3000mm, 2000*4000mm, 2000*6000mm,..
Configuration	Specifications
Laser Generator	GW/Raycus/IPG
Laser Cutting Head	Au3tech, Raytool,
CNC Controller	Au3tech, Cypcut
Servo driver system	Delta/Yaskawa/Pansonic
Speed Reducer	Shimpo Reducer, Japan
Rack and Pinion:	Taiwan CSK/TBI/HIWIN guide rails
Max.cutting speed	0-30m/min(Depending on the material and thickness)
X, Y, Z Axis Repeat PrecisionX, Y, Z Axis Repeat Precision	≤±0.03mm /m
Min line width	≤0.15mm
Maximum Empty Running Speed	120m/min
Driving way	Imported servo motor
Transmission way	Y-axis import gear rack double driver, X-axis imported ball screw
Cooling System	Water Cooling
Continuous working time	24 Hours
Power requirements	380V/3 Phases /50Hz or 60Hz
Machine size (L*W*H)	4500x2300x1800mm

FAQ
1.How long is the warranty period?
Whole machine warranty period is 1 year, laser source 2 years. If there is any problem during the period, we will solve it as soon as possible.
2.How long is the cable?
Different laser source have different option. For example, the normal cable length of raycus and max is about 9 meters.
3.How thick can 1500w-3000W be welded
1-8mm thick metal materials.
4.Is there a wire feeder?
We have a wire feeder to choose from. If you are interested, you can contact us and provide your email address.We will send more detailed pictures to your email.
5.Can aluminum and galvanized steel be welded?
Yes, it can.
6.Packaging
All our machines are packed in wooden boxes.
7.Language interface
Supports language customization, etc. You can also translate and insert to software.
