1500W CNC Tube and Plate Fiber Laser Cutting Machine for 8mm Stainless Steel Plate
Main Features: 1. Low maintenance --- it's transmited by Fiber cable, no need reflecting mirrors, no need to adjust the
|Transmit System||Dual Rack & Pinion Type|
|Locating Precisioon||<0.01 mm|
|Power Supply||AC 380V/50Hz or Depend User′s Requirement|
|Laser Beam Quality||<0.373mrad|
|Work Table||Saw Tooth Work Table|
|Position Speed||2000 mm/Min|
|Working Size||1500X3000mm ;2000X4000 mm|
|Transport Package||Wooden Packing|
|Production Capacity||30sets/Per Month|
1.Low maintenance--- it's transmited by Fiber cable, no need reflecting mirrors, no need to adjust the light route;2.Low consumption---The power is more than 30% lower than the ordinary cutting machine.3.Maintenance-free---For the fiber laser cutter, the reflect lens are no needed. It will help to save a lot of time when optical path is adjusted. The laser generator with longer lifetime which no need maintenance during usage.4.Environment friendly--Laser cutting will not creates any gases for the special cutting technology for steel sheet.
5.Low power consumption--- Energy saving and environmental friendly, lowest power consumption asthe highest photoelectric conversion with Fiber source. Only 20%-30% consumption compared with other lasercutting system.6.Low gas consumption--- no need mixed gas for cutting, high pressure air can also cutting steel.7.Maximum simultaneous positioning speed: 160m/min.
8 Precision: + - 0.05 mm.
9. Energy efficiency: greatly reduced power consumption.10. Excellent cutting quality for fine thic kness and medium thickness sheet metals.
The main technical :
|Laser generator working mode||Continuous/Modulation|
|Laser Cutting Head||Raytools compact USA Lasermech|
|Work size||3000mm x 1500mm|
|X axle stroke||3050mm|
|Z axle stroke||120mm|
|CNC control||PMAC/Industrial control computer with cutting software|
|X,Y Axis Position accuracy||±0.03mm|
|X,Y Axis Repeat position accuracy||±0.02mm|
|X, Y Axis max linkage speed||110m/min|
|Laser wavelength||1070 mm -1080 nm|
|Format supported||AI, PLT, DXF, etc|
|Auxiliary Gas||3 separate gas routes ( unique design)|
|Laser cutting nozzle||Dynamic focus following|
|Electronics and control||Controlling unit|
Mainly used for cutting carbon steel, silicon steel, stainless steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials cutting and so on.
The cutting product :
